Livery Guide for LNER

Information provided on the liveries and dates of prototype (the full-size) locomotives, coaches and freight vehicles has been obtained from a wide range of published sources and is provided here in good faith. Fox Transfers cannot accept liability for any errors in and/or omissions from this information and subsequent issues which may be caused.

Before ordering your transfers please check with illustrations of your selected prototype locomotive and with the various sizes, styles and colourways of lettering and numbering that we offer. We cannot guarantee that we have information relating to the above parameters for every locomotive at every stage of its life.

This livery guide gives transfer sheet references for the liveries/classes listed below for LNER.
Use the reference number in the search bar at the top of the page to find the item and then click the thumbnail for a detail description and enlarged view.

For 2mm/N - substitute FRH4 for FRH2 and for 7mm/0 substitute FRH4 for FRH7 (PLEASE NOTE THERE ARE LIMITED NAMEPLATE SETS AVAILABLE IN THESE 2 SCALES)

London & North Eastern Railway 1923-1948

Lettering and Numbering reference FRH4301 plain yellow loco lettering and numbering. (Later style : appropriate for the pre-war, wartime and post-war periods.)
Lettering and Numbering reference FRH4301/5 yellow - (These sheets may be used for locos in ex-works photographic grey and/or certain green liveried applications, but do not appear to have been in general use)
Lettering and Numbering reference FRH4301/10 white - (These sheets may be used for locos in ex-works photographic grey and/or certain green liveried applications, but do not appear to have been in general use).

BLACK LIVERIES - Generally (but not exclusively) the colouring for these locos/tenders would have been Yellow faced red and brown shadows with white highlights

GREEN LIVERIES - Generally (but not exclusively) the colouring for these locos/tenders would have been Gold faced red and black shadows with white highlights

Lettering and Numbering reference FRH4302 gold/red/brown (Alternative Larger Earlier size for Black locos)
Lettering and Numbering reference FRH4303 gold/red/brown (Alternative Smaller Earlier size for Black locos)*
Lettering and Numbering reference FRH4304 yellow/red/brown (Alternative Larger Earlier size for Black locos)
Lettering and Numbering reference FRH4305 yellow/red/brown (Alternative Smaller Earlier size for Black locos)*
Lettering and Numbering reference FRH4306 gold/red/black (Larger Later size for Garter Blue and Green locos)
Lettering and Numbering reference FRH4307 gold/red/black (Smaller Ealier size for Garter Blue and Green locos)*
Lettering and Numbering reference FRH4308 yellow/red/black (Larger Later size for Green locos)
Lettering and Numbering reference FRH4309 yellow/red/black (Smaller Earlier size for Green locos)*

*SMALLER EARLIER SIZE - These transfers (which include &s) were designed for liveries from 1923 until the early 30s to enable L & NER to be added to tenders and tanksides. They were superceded by the larger, later size to show LNER. Wartime repainting involved the deletion of L and R.

Gresley Hush-Hush 1935-1937/8

Lettering and Numbering reference FRH4315 including Bufferbeam numbering

Gresley A4 SILVER Streamliners 1935-1937/8 SILVER STREAMLINERS

Nameplates - available as transfers only on sheet FRH4310
Lettering and Numbering reference FRH4310 including Bufferbeam numbering
Coaching stock FRH4311 (THE SILVER JUBILEE), FRH4312 (WEST RIDING LTD) or FRH4313 (CORONATIION)

Gresley A4 Streamliners 1935-1937/8

Nameplates - the whole class is available in STAINLESS STEEL FEP4482ss - FEP4498ss (ie prefix code FEP followed by loco number).

Ogee GARTER BLUE LIVERY 1935-37/8

Lettering and Numbering reference FRH4300/1 (or FEPLNER&1-0 in etched format) Bufferbeam numbering FRH4300/2 (both sheets FRH4300)
Specific lining sheet reference FRH4355/3 (red/white)
Teak Coach Stock Branding - FRH4320
For other coaching stock sheets see bottom of page.

Gresley A4 Streamliners 1937-1948

Nameplates - the whole class is available in BRASS FEP2509-2510 for the initial 4 locomotives (ie prefix code FEP followed by loco number).
Balance of the class is available in BRASS FEP4482 - FEP4498 inclusive (ie prefix code FEP followed by loco number).

WARTIME BLACK LIVERY (Sept 1946-1948)

Loco Lettering Numbering and Bufferbeam Numbering FRH4300/4+5

Ogee GARTER BLUE LIVERY Late 1930s & Post War up to 1948

Lettering and Numbering reference FRH4306/1
Bufferbeam numbering FRH4306/A4
Specific lining sheet reference FRH4355/3 (red/white)
Teak Coach Stock Branding - FRH4320
For other coaching stock sheets see bottom of page.

GREEN LIVERY

Lettering and Numbering reference FRH4306/1 - Bufferbeam numbers FRH4306/2 (both sheets FRH4306)
Small detailing FRH4355/20 or FRH4355/21 (pre and post-war liveries)
UNLINED
Teak Coach Stock Branding - FRH4320
For other coaching stock sheets see bottom of page.

A3 GRESLEY CLASS

Nameplates - the whole class is available in FEP2500-FEP2508 : FEP2543-FEP2599 : FEP2743-FEP2797 : FEP4472-FEP4481 (ie prefix code FEP followed by loco number).

BLUE LIVERY

Lettering and Numbering reference FRH4306/1 - Bufferbeam numbers FRH4306/2 (both sheets FRH4306)
Specific Lining reference FRH4354/10 (white/black/white)
For the Flying Scotsman 4472 use sheets FRH4354/10TT for Twin Tender, FRH4354/10ST for Single Tender or FRH4354/10WT for Water Tender.
General Lining reference FRH4350 (white/black/white)
Crests sheet FRH4375
Teak Coach Stock Branding - FRH4320
For other coaching stock sheets see bottom of page.

A2/2 THOMPSON CLASS - Green Livery

Nameplates - the whole class is available in BRASS FEP501 - FEP506 (ie prefix code FEP followed by loco number).
Lettering and Numbering reference FRH4306/1 - Bufferbeam numbers FRH4306/2 (both sheets FRH4306)
